Two Wheeler Garage Equipments - Lifts |
|
|
|
|
Bike / Scooter Service Lift (OLS - 284) |
|
Standard scissor lift consist of a metal platform for lifting the vehicle for servicing. The lift top & base are connected thru. cross arrangement of shaft which uses pneumatic & hydraulic force to elevate the work area & can be easily shut it down when we adjuste it in lowered condition. Lift given sufficient work area or height to move around for servicing the vehicle. |
|
|
|
Type of ramp : Scissor
Mode : Hydraulic / Pneumatic operated
Shut height: 3499 mm
Structure : 711 mm – 1054 mm
Center: 800 mm – 1137 mm
Top sheet: 3353 mm
Size: 2769 mm |
|
|
|
|
Bike / Scooter Service Lift (OLS - 285) |
|
|
Type of ramp: Scissor
Mode : Hydraulic / Pneumatic operated
Shut height :10 Inch floor / pit mounted
Structure : CRC sheet / CRC pipe
Center : S.S top
Top sheet : M.S sheet powder coated with wheel clamping vice
Size : 1800 X 600 X 250 mm |
|
|
|
|
Bike / Scooter Service Lift (OLS - 286) |
|
Type of ramp - Scissor
Mode - Hydraulic operated
Shut height - 8 Inch floor / pit mounted
Structure - CRC sheet / CRC pipe
Size - 1800 X 600 X 200 mm |
|
|
|
|
Portable Bike / Scooter Service Lift (OLS - 287) |
|
- Type of ramp: Parallogram
Mode: Hydraulic operated
Shut height :230 mm floor / pit mounted
Structure : CRC sheet / CRC pipe
top sheet :M.S sheet powder coated with wheel clamping vice
Size: 2100 X 450 X 230 mm
Specially designed for scooter / motor cycle front / rear wheel servicing.
|
|
|
|
|
|
Bike / Scooter Service Lift (OLS - 288) |
|
|
Type of ramp: Scissor
Mode: Hydraulic / Pneumatic operated
Shut height: 8 Inch floor mounted
Structure: CRC sheet / CRC pipe
Center: S.S top with center stand clamping stand
Top sheet: S.S checkered sheet
Size: 1800 X 600 X 250 mm |
|
|
|
|
Bike / Scooter Service Lift (OLS - 289) |
|
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 8 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered top
Top sheet: S.S checkered sheet
Size: 1800 X 600 X 200 mm
With inbuilt smoke exhaust systems. |
|
|
|
|
|
Portable Bike / Scooter Service Lift
(OLS - 290) |
|
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 8 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered top
Top sheet: S.S checkered sheet
Size: 1800 X 600 X 200 mm
With inbuilt smoke exhaust systems. |
|
|
|
|
Bike / Scooter Service Lift (OLS - 291) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 8 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: S.S checkered Top
Top sheet: Aluminum checkered sheet with side panel top
Size: 1800 X 600 X 200 mm
With inbuilt smoke exhaust systems. |
|
|
|
|
|
Bike / Scooter Service Lift (OLS - 292) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 8 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: S.S checkered Top
Top sheet:M.S sheet powder coated
Size: 1800 X 600 X 200 mm
With front & rear wheel dismantling provision folding type & front &rear wheel locking mechanism inbuilt in the lift . |
|
|
|
|
|
Bike / Scooter Service Lift (OLS - 293) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 8 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: S.S checkered Top with vice & wheel stopper
Top sheet:S.S checkered Top
Size: 1800 X 600 X 200 mm |
|
|
|
|
Bike / Scooter Service Lift (OLS - 294) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 10 Inch floort mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered top with vice & wheel stopper
Top sheet: S.S checkered sheet with side panel top
Size: 1800 X 600 X 250 mm
Hydraulic power pack inbuilt in the lift |
|
|
|
|
|
Bike / Scooter Service Lift (OLS - 295) |
|
Type of ramp: Scissor
Mode: Manual Hydraulic operated
Shut height: 8 Inch floort mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered top
Top sheet: M.S powder coated top
Size: 1800 X 600 X 200 mm
Top platform 360 rotatable suitable for demo in showroom/ training centres. |
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 296 |
|
Type of ramp: Scissor
Mode: Manual Hydraulic operated
Structure: CRC sheet / CRC pipe
Top sheet: S.S top
Size: 2450 X 900 X 250 mm.
Inbuilt smokeless system.
Maximum load capacity 800kg. |
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 297) |
|
Type of ramp: Scissor
Mode: Manual Hydraulic operated
Structure: CRC sheet / CRC pipe
Top sheet: S.S top
Size: 2450 X 900 X 250 mm.
Inbuilt smokeless system.
Maximum load capacity 800kg. |
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 298) |
|
Type of ramp: Scissor
Mode: Pneumatic operated
Shut height: 10 Inch floort mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered sheet
Top sheet: M.S Top Powder Coated
Size: 1800 X 600 X 250 mm
With front & rear wheel dismantling provision folding type 2 front &rear wheel locking mechanism inbuilt in the lift |
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 299) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height:10 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered sheet
Top sheet: S.S Top
Size: 1800 X 600 X 250 mm |
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 300) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 10 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered top
Top sheet: S.S Top
Size: 2464 X 1060 X 300 mm
Maximum load capacity 1000kg |
|
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 301) |
|
Type of ramp: Scissor Type
Mode: Hydraulic operated
Structure: CRC sheet / CRC pipe
Top sheet: S.S checkered top
Center: S.S top
Size: 2000 X 700 X 250 mm
Maximum load capacity 800kg
Inbuilt power pack with 1 hp motor with side protector |
|
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 302) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Structure: CRC sheet / CRC pipe.
Top sheet: Aluminum checkered top
Size: 2360 X 762 X 250 mm
Inbuilt smokeless system.
Maximum load capacity 800kg |
|
|
|
|
|
Motorcycle Service Mechanical Lift with toolbox (OLS - 329) |
|
Mode: Manual
Structure: CRC sheet / CRC pipe
Top sheet: Aluminum checkered top
Maximum load capacity 800kg
|
|
|
|
Service Lifts & Accessories |
Heavy Duty Bike Service Lift (OLS - 303) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 10 Inch floor mounted
Structure: CRC sheet / CRC pipe.
Top sheet: M.S sheet powder coated
Size: 2438 X 914 X 250 mm
Dual smoke collector system
Maximum load capacity 1000kg. |
|
|
|
|
|
Heavy Duty Bike Service Lift (OLS - 304) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 12 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe.
Top sheet: Aluminum checkered top
Size: 2464 X 1065 X 300 mm
Maximum load capacity 1000kg. |
|
|
|
|
Heavy Duty Service Lifts & Accessoriesd |
|
 |
|
 |
|
Loading / Unloading LiftS |
|
Loading/Unloading Lift For Two Bikes (OLS - 308) |
|
- Robust structure made of M.S.
- Checkered sheet on top.
- Loading / unloading lift for two bike.
- Hydraulic operated.
- Side frame for safety feature.
- Maximum height - 14 feet.
- Maximum capacity - 400kg.
|
 |
|
|
|
|
Loading / Unloading Lift For Four Bikes
(OLS - 309) |
|
- Robust structure made of M.S .
- Checkered sheet on top .
- Loading / unloading lift for 4 bikes .
- Hydraulic operated .
- Side frame for safety.
- Loading /unloading capacity 800 kg .
- Maximum height for lift 15 feet .
|
|
|
|
|
|
Loading Unloading Trolley (OLS - 310 ) |
|
- Robust structure.
- Checkered sheet top .
- Manual Hydraulic operated .
- Powder coated .
|
|
|
|
|
Standard Service Lifts |
|
Hydro Pneumatic Washing Lift For Four Bikes (OLS - 311 ) |
|
- Specially designed for washing 4 bike at a time.
- Structure made of M.S & Seamless pipe.
- Easy to operate.
- Hydro-pneumatic lift.
- It required less space.
- Weight Capacity 1.2 Ton.
- Wheel vice.
- Pit Mounted
- Gives quality wash.
- Curtain provided to avoid splitting of water or dirt.
- Reduces the manpower.
- Less consumable time to wash four bike.
- Sufficient space for person to move b/w to bikes for better wash.
|
|
|
|
|
|
Hydro Pneumatic Washing Lift For Two Bikes (OLS - 312) |
|
• Structure made of m.s.
• Wheel vice.
• Single person operated.
• Easy handling.
• Pneumatic operated.
• Checkered sheet on the top.
• FR to remove the moisture form air.
• Capacity 400 kg.
• Less space required.
• It reduce the man power.
• Two bike simultaneously wash at a time.
• It gives excellent wash in less consumable time.
• It gives sufficient space to move b/w two bikes.
• It can be installed in room or in open space. floor mounted.
|
|
|
|
|
|
Multi Jet High Pressure Washing Booth (OLS - 313) |
|
Unique concept in automated washing with the help of high pressure multi jet spray nozzles provides excellent quality wash in less time |
|
|
|
|
Lift & Stands |
|
Drum Lifter (OLS - 314) |
|
- Specially designed for lifting the drum & move easily from on shop floor.
- Structure made of M.S pipe / M.S sheet .
- Hydraulic foot operated function .
- 4 castor wheel for easy movement .
- Easy to operate.
|
|
|
|
|
|
|
Multi Utility Roller Test Bench For Two Wheeler (OLS - 315) |
|
- Structure made of M.S sheet / pipe.
- Specially designed for testing the fuel consumption of 2 wheeler.
- Inbuilt exhaust system.
- Testing is safe.
- Increases Profitability of Service Center.
- It takes 4-5 minutes in process.
|
|
|
|
|
|
|
Genset Engine Service Lift (OLS - 316) |
|
- Type of ramp: Scissor
- Mode: Manual hyd. pump
- Structure : CRC sheet / CRC pipe
- Top sheet : M.S top covered with rubber sheet
- Size: 1120 X 965 mm
- Working height 610 mm.
- maximum load capacity 500kg.
- Movable castor wheel.
|
|
|
|
|
|
|
Front & Rear Wheel Paddock Stand (OLS - 317) |
|
- Specially designed stand for holding rear & front arm, under bracket of sports bike at the time of servicing .
- Paint / Powder Coated.
|
|
 |
|
|
|
|
Center Stand (OLS - 318) |
|
- Specially designed for holding / lifting the heavy bikes centrally.
- Structure made of M.S pipe or M.S sheet.
- Hydraulic operated.
- Rubber sheet at the center to avoid scratch.
- Easy to operate.
- Light in weight.
|
|
|
|
|
|
|
Parking Trolley (OLS - 319) |
|
Parking Trolley is the perfect accessory for motorcycles with side stand which need to be rolled around or repositioned in a narrow space. Once your bike is placed on the parking trolley very little effort is required to move and rotate a heavy motorcycle. Allows a rider to park and move their motorcycle anywhere in the garage or shop when space is an issue. |
|
|
|
|
|
|
Bike Hanger (OLS - 320) |
|
- Structure made of heavy duty M.S pipe & sheet.
- 4 castor wheel for easy movement.
- Chain pulley arrangement.
- Specially designed to hold the bike.
- Maximum load capacity 1 Ton
|
|
|
|
|
Power Pack |
|
OLS - 321 |
OLS - 322 |
 |
 |
|
Hydraulic Power Pack (OLS - 321 & OLS - 322) |
|
Hydraullic power pack is designed by positive displacement type gear / piston pump with high pressure relief valve to safe guard the system overload, driven by electric motor to operate lift. |
- Hydro - electric power pack with manual pump attached
- Motor 1HP 3 phase / single phase solenoid valve operated with on/off switch for up /down lift.
- Tank capacity 20 Ltr.
- With MCB contactor &LED bulb indicators
- Maximum pressure for pump 200 kg (Gear Pump ).
|
|
|
|
|
|
|
Single Solenoid Valve
(OLS - 323) |
Multi Solenoid Valve
(OLS - 324) |
 |
 |
|
- Hydro - electric power pack
- Motor 2 HP 3 phase / single phase solenoid valve operated with on/off switch for up /down lift .
- Tank capacity 20 Ltr .
- with MCB contactor & bulb indicators
- Maximum pressure for pump 300 - 400 kg
( Piston Pump ) .
|
|
|
|
|
|
|
Motorized Power Pack with
Hand Operated Pump
(OLS - 325) |
Motorized Power Pack with Foot Operated Pump
(OLS - 326) |
 |
 |
|
Hydraulic Power Pack with Dual Outlets
(OLS - 327)
|
Manual Power Pack
(OLS - 328)
|
 |
 |
|
