| Two Wheeler Garage Equipments - Big bike |
|
|
| Heavy Duty Service Lifts & Accessoriesd |
| |
 |
| |
 |
|
|
Heavy Duty Bike Service Lift (OLS - 296
|
|
Type of ramp: Scissor
Mode: Manual Hydraulic operated
Structure: CRC sheet / CRC pipe
Top sheet: S.S top
Size: 2450 X 900 X 250 mm.
Inbuilt smokeless system.
Maximum load capacity 800kg.
|
|
| |
|
|
Heavy Duty Bike Service Lift (OLS - 297)
|
|
Type of ramp: Scissor
Mode: Manual Hydraulic operated
Structure: CRC sheet / CRC pipe
Top sheet: S.S top
Size: 2450 X 900 X 250 mm.
Inbuilt smokeless system.
Maximum load capacity 800kg.
|
|
| |
|
|
|
| Heavy Duty Bike Service Lift (OLS - 298) |
|
Type of ramp: Scissor
Mode: Pneumatic operated
Shut height: 10 Inch floort mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered sheet
Top sheet: M.S Top Powder Coated
Size: 1800 X 600 X 250 mm
With front & rear wheel dismantling provision folding type 2 front &rear wheel locking mechanism inbuilt in the lift
|
|
| |
|
|
| Heavy Duty Bike Service Lift (OLS - 299) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height:10 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered sheet
Top sheet: S.S Top
Size: 1800 X 600 X 250 mm
|
|
| |
|
|
| |
| Heavy Duty Bike Service Lift (OLS - 300) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 10 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe
Center: Aluminum checkered top
Top sheet: S.S Top
Size: 2464 X 1060 X 300 mm
Maximum load capacity 1000kg
|
|
| |
|
| |
|
| |
| Heavy Duty Bike Service Lift (OLS - 301) |
|
Type of ramp: Scissor Type
Mode: Hydraulic operated
Structure: CRC sheet / CRC pipe
Top sheet: S.S checkered top
Center: S.S top
Size: 2000 X 700 X 250 mm
Maximum load capacity 800kg
Inbuilt power pack with 1 hp motor with side protector
|
|
| |
|
|
| |
| Heavy Duty Bike Service Lift (OLS - 302) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Structure: CRC sheet / CRC pipe.
Top sheet: Aluminum checkered top
Size: 2360 X 762 X 250 mm
Inbuilt smokeless system.
Maximum load capacity 800kg
|
|
| |
|
|
| |
| Heavy Duty Bike Service Lift (OLS - 303) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 10 Inch floor mounted
Structure: CRC sheet / CRC pipe.
Top sheet: M.S sheet powder coated
Size: 2438 X 914 X 250 mm
Dual smoke collector system
Maximum load capacity 1000kg.
|
|
| |
|
|
| |
| Heavy Duty Bike Service Lift (OLS - 304) |
|
Type of ramp: Scissor
Mode: Hydraulic operated
Shut height: 12 Inch floor / pit mounted
Structure: CRC sheet / CRC pipe.
Top sheet: Aluminum checkered top
Size: 2464 X 1065 X 300 mm
Maximum load capacity 1000kg.
|
|
| |
|
